产品型号
采样率
-
-
通道数
-
-
分辨率
-
-
量程
带宽
耦合
阻抗
缓存
接口
- LD814x
10-80Msps，PCIe x4
- LD815x
100-250Msps,PCIe x8
- LD816x
500Msps,±1,±2V
- LD817x
1G-3Gsps,±1,±2V
- LD816xA
500Msps,交流耦合
- LD817xA
1G-3Gsps,交流耦合
- LD816xC
500Msps交直流50Ω/1MΩ
- LD817xC
1Gsps,交直流,PCIe Gen2
- LD8142-10M12
10Msps
2
12bit
±1、±2、±5、±10v
DC-5MHz
AC/DC
50Ω/1MΩ
512MB
PCIe x4 Gen2
- LD8142-10M14
10Msps
2
14bit
±1、±2、±5、±10v
DC-5MHz
AC/DC
50Ω/1MΩ
512MB
PCIe x4 Gen2
- LD8142-10M16
10Msps
2
16bit
±1、±2、±5、±10v
DC-5MHz
AC/DC
50Ω/1MΩ
512MB
PCIe x4 Gen2
- LD8144-10M12
10Msps
4
12bit
±1、±2、±5、±10v
DC-5MHz
AC/DC
50Ω/1MΩ
512MB
PCIe x4 Gen2
- LD8144-10M14
10Msps
4
14bit
±1、±2、±5、±10v
DC-5MHz
AC/DC
50Ω/1MΩ
512MB
PCIe x4 Gen2
- LD8144-10M16
10Msps
4
16bit
±1、±2、±5、±10v
DC-5MHz
AC/DC
50Ω/1MΩ
512MB
PCIe x4 Gen2
- LD8148-10M12
10Msps
8
12bit
±1、±2、±5、±10v
DC-5MHz
AC/DC
50Ω/1MΩ
512MB
PCIe x4 Gen2
- LD8148-10M14
10Msps
8
14bit
±1、±2、±5、±10v
DC-5MHz
AC/DC
50Ω/1MΩ
512MB
PCIe x4 Gen2
- LD8148-10M16
10Msps
8
16bit
±1、±2、±5、±10v
DC-5MHz
AC/DC
50Ω/1MΩ
512MB
PCIe x4 Gen2
- LD8142-20M12
20Msps
2
12bit
±1、±2、±5、±10v
DC-10MHz
AC/DC
50Ω/1MΩ
512MB
PCIe x4 Gen2
- LD8142-20M14
20Msps
2
14bit
±1、±2、±5、±10v
DC-10MHz
AC/DC
50Ω/1MΩ
512MB
PCIe x4 Gen2
- LD8142-20M16
20Msps
2
16bit
±1、±2、±5、±10v
DC-10MHz
AC/DC
50Ω/1MΩ
512MB
PCIe x4 Gen2
- LD8144-20M12
20Msps
4
12bit
±1、±2、±5、±10v
DC-10MHz
AC/DC
50Ω/1MΩ
512MB
PCIe x4 Gen2
- LD8144-20M14
20Msps
4
14bit
±1、±2、±5、±10v
DC-10MHz
AC/DC
50Ω/1MΩ
512MB
PCIe x4 Gen2
- LD8144-20M16
20Msps
4
16bit
±1、±2、±5、±10v
DC-10MHz
AC/DC
50Ω/1MΩ
512MB
PCIe x4 Gen2
- LD8148-20M12
20Msps
8
12bit
±1、±2、±5、±10v
DC-10MHz
AC/DC
50Ω/1MΩ
512MB
PCIe x4 Gen2
- LD8148-20M14
20Msps
8
14bit
±1、±2、±5、±10v
DC-10MHz
AC/DC
50Ω/1MΩ
512MB
PCIe x4 Gen2
- LD8148-20M16
20Msps
8
16bit
±1、±2、±5、±10v
DC-10MHz
AC/DC
50Ω/1MΩ
512MB
PCIe x4 Gen2
- LD8142-40M12
40Msps
2
12bit
±1、±2、±5、±10v
DC-20MHz
AC/DC
50Ω/1MΩ
1GB
PCIe x4 Gen2
- LD8142-40M14
40Msps
2
14bit
±1、±2、±5、±10v
DC-20MHz
AC/DC
50Ω/1MΩ
1GB
PCIe x4 Gen2
- LD8142-40M16
40Msps
2
16bit
±1、±2、±5、±10v
DC-20MHz
AC/DC
50Ω/1MΩ
1GB
PCIe x4 Gen2
- LD8144-40M12
40Msps
4
12bit
±1、±2、±5、±10v
DC-20MHz
AC/DC
50Ω/1MΩ
1GB
PCIe x4 Gen2
- LD8144-40M14
40Msps
4
14bit
±1、±2、±5、±10v
DC-20MHz
AC/DC
50Ω/1MΩ
1GB
PCIe x4 Gen2
- LD8144-40M16
40Msps
4
16bit
±1、±2、±5、±10v
DC-20MHz
AC/DC
50Ω/1MΩ
1GB
PCIe x4 Gen2
- LD8148-40M12
40Msps
8
12bit
±1、±2、±5、±10v
DC-20MHz
AC/DC
50Ω/1MΩ
1GB
PCIe x4 Gen2
- LD8148-40M14
40Msps
8
14bit
±1、±2、±5、±10v
DC-20MHz
AC/DC
50Ω/1MΩ
1GB
PCIe x4 Gen2
- LD8148-40M16
40Msps
8
16bit
±1、±2、±5、±10v
DC-20MHz
AC/DC
50Ω/1MΩ
1GB
PCIe x4 Gen2
- LD8142-80M12
80Msps
2
12bit
±1、±2、±5、±10v
DC-40MHz
AC/DC
50Ω/1MΩ
1GB
PCIe x4 Gen2
- LD8142-80M14
80Msps
2
14bit
±1、±2、±5、±10v
DC-40MHz
AC/DC
50Ω/1MΩ
1GB
PCIe x4 Gen2
- LD8142-80M16
80Msps
2
16bit
±1、±2、±5、±10v
DC-40MHz
AC/DC
50Ω/1MΩ
1GB
PCIe x4 Gen2
- LD8144-80M12
80Msps
4
12bit
±1、±2、±5、±10v
DC-40MHz
AC/DC
50Ω/1MΩ
1GB
PCIe x4 Gen2
- LD8144-80M14
80Msps
4
14bit
±1、±2、±5、±10v
DC-40MHz
AC/DC
50Ω/1MΩ
1GB
PCIe x4 Gen2
- LD8144-80M16
80Msps
4
16bit
±1、±2、±5、±10v
DC-40MHz
AC/DC
50Ω/1MΩ
1GB
PCIe x4 Gen2
- LD8148-80M12
80Msps
8
12bit
±1、±2、±5、±10v
DC-40MHz
AC/DC
50Ω/1MΩ
1GB
PCIe x4 Gen2
- LD8148-80M14
80Msps
8
14bit
±1、±2、±5、±10v
DC-40MHz
AC/DC
50Ω/1MΩ
1GB
PCIe x4 Gen2
- LD8148-80M16
80Msps
8
16bit
±1、±2、±5、±10v
DC-40MHz
AC/DC
50Ω/1MΩ
1GB
PCIe x4 Gen2
